주낙하산(MC1-1B,C,D,E & T-10B,C,D)고장 또는 작동불능시 비상시에 사용하는 낙하산으로서 강하자의 가슴에 착용하여 강하자가 비상시 펼침줄(Ripcord)을 당겨 낙하산을 전개함.
TECHNICAL SPECIFICATION
Suspended Load 300 LBS 300 LBS
Weight(APP) 12 LBS 12 LBS
Max.Deployment( A/C SPEED) 150 KNOTS 150 KNOTS
Min. Jump Height 300 FT 300 FT
Deployment Time 3.3 sec 3.3 sec
Decent Rate 6.5 m/sec 6.5 m/sec
Shape Flat Circular Flat Circular
Canopy Diameter 24 Ft.(Nominal) 24 Ft.(Nominal)
No. Of Canopy Gores 24 > 24
No. Of Suspension Line 24 24
No. of Panels Per Gore 4 4
No. of Vent Lines 12 12
No. of Suspension Lines 30 30
Length of Suspension Line 20.5 ft 20.5 ft
No. of Steering Lines x x
No. of Steering Orifice x x
No. of Pocket Bands 24 24
Canopy Material 1.1 oz.Ripstop Nylon 1.1 oz.Ripstop Nylon
