: product > personnel > mc1-1b
MC1-1C가 보급되기전 가장 보편적 기동형 낙하산으로 무장강하가 가능한 전술용 및 훈련용 주력 모델임.
캐노피(산체)는 기본적으로 T-10B와 동일하나 공기구멍과 조종줄이 부착되어 강하중 수평 이동 및 360도방향 전환이 가능함.
TECHNICAL SPECIFICATION
Suspended Load
300 LBS
Weight(APP)
31 LBS
Max.Deployment( A/C SPEED)
150 KNOTS
Min. Jump Height
500 FT
Deployment Time
2.8 sec
Decent Rate
5.5 m/sec
Forward Rate
3.8 m/sec
Rate of Turn
360 0 in 8.8 sec
Shape
PARABOLIC
canopy Diameter
35 Ft.(Nominal)
24.5 Ft. (Skirt)
No. of Canopy Gores
30
No. of Suspension Line
30
No. of Panels Per Gore
5
No. of Radial Tapes
30
No. of Vent Lines
15
No. of Suspension Lines
30
Length of Suspension Line
25.5 ft(7.77m)
No. of Steering Lines
2
No. of Steering Orifice
11 "TU" Type
No. of Pocket Bands
15
Canopy Material
1.1 oz.Ripstop Nylon
