: product > deceleration > F-5 air craft
항공기가 활주로 착륙시 항공기의 속도를 감속시키는 낙하산으로 항공기 호라주로 이탈방지와 급제동으로 인한 타이어 마모방지등을 위한 항공기 감속 낙하산
TECHNICAL SPECIFICATION
Type
Ring Slot
Size(Diameter )
15 feet diameter
Weight of Parachute
19 pounds
Maximum Deployment Speed
165 knots
Maximum Ambient Temperature
(inside Chute Compartment)
250℉
Diameter
15 feet
No of Gore
20
Each Gore Section
5 panel
No of Suspension Line
20
Length of Suspension Line
180.0 Inch
No of Radial Tape
20
No of Vertical Tape
20
Slot
3.25 Inch
Link Connector
4
Length of Riser
18 ft 11 in
Canopy Material
2.25 oz.Cloth Nylon
