Domestic only military parachute manufacturing industry
 : product > escape > b-12 &20
비전투기 조종사및 승무원이 항공기기 고장시 조종사와 승무원의 비상탈출용 낙하산으로서 개방손잡이을 당겨 유도산에의해 낙하산을 전개시키며,사용 운용에 따라 자동 산개기를 부착 적용 할 수가 있음.
TECHNICAL SPECIFICATION
Suspended Load 300 LBS 300 LBS
Weight(APP) 26 LBS 31 LBS
Decent Rate 5.5 m/sec 5.5 m/sec
Forward Rate - 2.0 m/sec
Rate Of Turn 360 0 in 10 sec 360 0 in 10 sec
Shape Flat Circular Flat Circular
Canopy Diameter 28 ft.(Nominal) 28 ft.(Nominal)
No. of Canopy Gores 28 28
No. of Suspension Line 28 28
No. of Panels Per Gore 5 5
No. of Vent Lines 14 14
No. of Suspension Lines 28 28
Length of Suspension Line 22 ft 10 in 22 ft 10 in
No. of Steering Lines x x
No. of Steering Orifice x x
No. of Pocket Bands x x
